VIAVI ONEEXPERT ONX-620 ONX-CATV TECH PACKAGE 3 ONX-620D31-4285-1010-TP3 ONE EXPERT TSX
VIAVI ONEEXPERT ONX-620 ONX-CATV TECH PACKAGE 3 ONX-620D31-4285-1010-TP3 ONE EXPERT TSX
Product Description
STOCK PHOTO
OneExpert CATV
The OneExpert CATV signal analysis meter platform makes every technician an expert by verifying
network performance and making troubleshooting simpler, faster, and more powerful than ever.
OneExpert CATV helps field technicians fix problems right—the first time. A multi-touch, user-friendly interface and OneCheck™ automated tests ease complex tasks with a simple dashboard with clear pass/fail results. And, its future-proof modularity ensure years of use supporting cable television and home networks.
The OneExpert platform empowers techs for quick, accurate testing and troubleshooting, with models/packages designed to address the specific needs of different work groups. As technology evolves, the future-proof platform adapts easily and capably with thorough state-of-the-art tests. Service providers must be able to adapt, quickly deploy new services and operate at high efficiency in order to maintain the highest levels of reliability and customer satisfaction.
Benefits
Simple – Every technician is an expert
- Channel Plans automatically built by the meter
- Dashboard simplifies and identifies RF issues
- Expertise is built in – Session Expert™ helps technicians identify issues and fix them
- Connects to the cloud – quickly and easily – ensuring consistency via StrataSync™
Fast – Testing and troubleshooting is faster than ever
- Downstream scan including MER/BER in about 60 seconds​
- Ingress and Downstream testing performed simultaneously
- 15x more Downstream coverage in half the time of current generation meters
Powerful – Get the most from your investment
- DOCSIS 3.1 physical and service performance testing
- DOCSIS 3.0, 32x8 DOCSIS, Wi-Fi, Ethernet 1Gbps capable
- Add-on module capable to support future needs
- Field exchangeable DOCSIS and RF unit reduces cost of ownership
- Network expansion-ready with dual diplexers to support 42 and 85 or 65 and 85 MHz networks
Applications
- Troubleshoot service issues between the TAP, Ground Block and CPE
- Identify and fix intermittent issues related to QAM carriers and the home network
- Verify WiFi signal strength and availability in 2.4GHz and 5GHz networks
- Business Service turn-up and troubleshooting
- Gigabit service testing with TrueSpeed™
- PON and RFOG installation and troubleshooting including inspection, power levels, and RF performance
Key Features
- DuoPort™ design with PosiScan™ -- a VIAVI Exclusive -- ensures proper connection and testing of Ingress Scan and Downstream tests, helping techs do the job right the first time
- AutoChannel™ - Automatically identifies channel plan
- Cloud Enabled via StrataSync™ to track test results and compliance
- OneCheck dashboard clearly displays summarized results of the entire lineup, including MER/BER in about 60 seconds, with simple identification of faults needing attention
- Expertise Built In – Session Expert -- offers background analysis that identifies issues consistently between technicians, suggests actions that help technicians fix problems, and provides VIAVI expertise and algorithms built into a simple test
- Built in Usage Guide – learn to use the meter on the job
- Advanced capabilities:
- DOCSIS 3.1 physical and service performance
- 32x8 DOCSIS for Gigabit speeds
- WiFi 2.4GHz and 5GHz, Bluetooth
- Dual GigE Ethernet with optional TrueSpeed™ for testing at ONT or CM
- Optional Fiber Scope and Power Meter
- Forward sweep to 1.2 GHz, reverse sweep to 200 MHz
- Sweep backward compatible with SDA/DSAM gear
This product is StrataSync-enabled
StrataSync is a hosted, cloud-based solution that provides asset, configuration, and test data management for VIAVI instruments and ensures all instruments have the latest software and options installed. StrataSync Core supports the OneExpert platform at no charge. StrataSync Plus is also available for enhanced data management capability.
SALE INCLUDES:
(1) ONX-620 (ONX-620D31-4285-1010-TP3)
(1) CASE WITH SHOULDER STRAP (GLOVE)
(1) AC ADAPTER / CHARGER WITH POWER CORD
(1) IN-VEHICLE DC-DC CHARGER
THIS SALE IS FOR A PREOWNED VIAVI ONX-620 THAT IS PRE CONFIGURED. PLEASE VIEW THE DETAILS BELOW TO MAKE SURE THAT IT MEETS YOUR SPECIFICATIONS.
INSTRUMENT MAY SHOW SIGNS OF PREVIOUS USE. PLEASE FEEL FREE TO CONTACT US WITH ANY QUETIONS THAT YOU MAY HAVE.
ONX-620 TECH PACKAGE 3. PART NUMBER: ONX-620D31-4285-1010-TP3 DETAILS BELOW.
|
ONX-620D31-4285-1010-TP3 |
ONX Feature Bundle |
|||||
|
Feature Matrix |
ONX-620 |
ONX-630 |
||||
|
n = Standard with Package. N/A = Feature not Available for this package. Optional = Feature or option can be added. (after purchase) |
TECH PACKAGE 1 |
TECH PACKAGE 2 |
TECH PACKAGE 3 |
TECH PACKAGE 4 |
TECH PACKAGE 5 |
|
|
OneCheck |
Dashboard with ingress scan, downstream summary, DOCSIS summary, and Session Expert summary |
n |
n |
n |
n |
n |
|
OneCheck details screens |
Ingress scan — full graphic view |
n |
n |
n |
n |
n |
|
OneCheck downstream details |
Full scan with channel details — level, MER, BER, C/N, Echo, GD, ICFR |
n |
n |
n |
n |
n |
|
System view (max dB delta, max video delta) |
n |
n |
n |
n |
n |
|
|
Favorites |
n |
n |
n |
n |
n |
|
|
Tilt |
n |
n |
n |
n |
n |
|
|
Smart scan |
N/A |
N/A |
n |
n |
n |
|
|
MER graph — all channels |
N/A |
N/A |
n |
n |
n |
|
|
BER graph — all channels |
N/A |
N/A |
n |
n |
n |
|
|
Off-air ingress detection (downstream ingress under carrier) |
n |
n |
n |
n |
n |
|
|
OneCheck DOCSIS details |
Downstream DOCSIS channel scan with channel details — level, MER, BER, C/N, echo, GD, ICFR |
n |
n |
n |
n |
n |
|
Upstream DOCSIS channel scan with channel details — TX level, modulation type, ICFR |
N/A |
n |
n |
n |
n |
|
|
DOCSIS throughput |
N/A |
n |
n |
n |
n |
|
|
DOCSIS packet quality |
N/A |
n |
n |
n |
n |
|
|
OneCheck — Session Expert details |
Problems detected table |
n |
n |
n |
n |
n |
|
Suggested actions table |
n |
n |
n |
n |
n |
|
|
Ingress comparison between TAP and GB |
n |
n |
n |
n |
n |
|
|
Drop analysis between TAP and GB |
n |
n |
n |
n |
n |
|
|
Detailed downstream comparison between TAP, GB, and CPE |
n |
n |
n |
n |
n |
|
|
Detailed SmartScan comparison between TAP, GB, and CPE |
N/A |
N/A |
n |
n |
n |
|
|
Detailed Off-air ingress comparison between TAP, GB and CPE |
n |
n |
n |
n |
n |
|
|
Detailed DOCSIS comparison between TAP, GB, and CPE |
n |
n |
n |
n |
n |
|
|
Detailed DOCSIS service test comparison between TAP, GB, and CPE |
N/A |
n |
n |
n |
n |
|
|
Feature Matrix |
ONX-620 |
ONX-630 |
||||
|
n = Standard with Package. N/A = Feature not Available for this package. Optional = Feature or option can be added. (after purchase) |
TECH PACKAGE 1 |
TECH PACKAGE 2 |
TECH PACKAGE 3 |
TECH PACKAGE 4 |
TECH PACKAGE 5 |
|
|
ChannelCheck |
Full scan with channel details — level, MER, BER, C/N, Echo, GD, ICFR |
n |
n |
n |
n |
n |
|
DS Spectrum w/ Ingress under the carrier (7-channels wide) |
n |
n |
n |
n |
n |
|
|
System view (max dB delta, max video delta) |
n |
n |
n |
n |
n |
|
|
Favorites graph (up to 16 Ch) |
n |
n |
n |
n |
n |
|
|
Tilt |
n |
n |
n |
n |
n |
|
|
DQI over time |
n |
n |
n |
n |
n |
|
|
Level over time |
N/A |
N/A |
n |
n |
n |
|
|
MER over time |
N/A |
N/A |
n |
n |
n |
|
|
BER over time |
N/A |
N/A |
n |
n |
n |
|
|
Downstream in-channel response graph |
N/A |
N/A |
n |
n |
n |
|
|
SmartScan™ |
N/A |
N/A |
n |
n |
n |
|
|
Constellation |
n |
n |
n |
n |
n |
|
|
DOCSIS 3.1 testing |
OFDM signal detection and identification in scan - automatic |
Optional |
Optional |
Optional |
n |
n |
|
OFDM signal measurement |
Optional |
Optional |
Optional |
n |
n |
|
|
OFDM signal MER throughout channel band over time |
Optional |
Optional |
Optional |
n |
n |
|
|
OFDM signal level variation |
Optional |
Optional |
Optional |
n |
n |
|
|
OFDM ingress under carrier analysis |
Optional |
Optional |
Optional |
n |
n |
|
|
PLC detection, lock status, level, MER, CWE |
Optional |
Optional |
Optional |
n |
n |
|
|
NCP lock status, CWE |
Optional |
Optional |
Optional |
n |
n |
|
|
Profile analysis - lock status, CWE |
Optional |
Optional |
Optional |
n |
n |
|
|
Bonding verification, SC-QAM and OFDM |
Optional |
Optional |
Optional |
n |
n |
|
|
Throughput testing to 1 Gbps or greater - DOCSIS & Ethernet |
Optional |
Optional |
Optional |
n |
n |
|
|
Feature Matrix |
ONX-620 |
ONX-630 |
||||
|
n = Standard with Package. N/A = Feature not Available for this package. Optional = Feature or option can be added. (after purchase) |
TECH PACKAGE 1 |
TECH PACKAGE 2 |
TECH PACKAGE 3 |
TECH PACKAGE 4 |
TECH PACKAGE 5 |
|
|
DOCSISCheck |
Downstream DOCSIS channel scan with channel details — level, MER, BER, C/N, echo, GD, ICFR |
n |
n |
n |
n |
n |
|
DQI over time |
n |
n |
n |
n |
n |
|
|
Level over time |
N/A |
N/A |
n |
n |
n |
|
|
MER over time |
N/A |
N/A |
n |
n |
n |
|
|
BER over time with ES/SES |
N/A |
N/A |
n |
n |
n |
|
|
Downstream in-channel response graph |
N/A |
N/A |
n |
n |
n |
|
|
Upstream DOCSIS channel scan with channel details — TX level, modulation type, ICFR |
n |
n |
n |
n |
n |
|
|
Transmit over time |
n |
n |
n |
n |
n |
|
|
DOCSIS upstream in-channel frequency response graph |
N/A |
N/A |
n |
n |
n |
|
|
Speed Check – throughput |
N/A |
n |
n |
n |
n |
|
|
Packet quality — packet loss, round trip delay, jitter |
N/A |
n |
n |
n |
n |
|
|
Ping/trace route |
N/A |
n |
n |
n |
n |
|
|
Pass through modem RJ-45 port |
N/A |
n |
n |
n |
n |
|
|
Ethernet testing |
Ethernet |
N/A |
n |
n |
n |
n |
|
Speed Check - throughput |
N/A |
n |
n |
n |
n |
|
|
Ping/Trace route |
N/A |
n |
n |
n |
n |
|
|
FTP/HTTP upload/download |
N/A |
n |
n |
n |
n |
|
|
Web browser |
n |
n |
n |
n |
n |
|
|
VoIP SIP |
N/A |
n |
n |
n |
n |
|
|
VoIP MOS |
N/A |
Optional |
Optional |
Optional |
Optional |
|
|
IP video |
N/A |
Optional |
Optional |
Optional |
Optional |
|
|
TrueSpeed™ |
N/A |
Optional |
Optional |
Optional |
Optional |
|
|
WiFi testing |
WiFi - 2.4GHz and 5GHz |
n |
n |
n |
n |
n |
|
n |
n |
n |
n |
n |
||
|
N/A |
n |
n |
n |
n |
||
|
Expert modes |
Test point templates, custom limit plans and live/stored measurement comparisons |
N/A |
N/A |
N/A |
n |
n |
|
Channel Expert |
N/A |
N/A |
N/A |
n |
n |
|
|
DOCSIS Expert |
N/A |
N/A |
N/A |
n |
n |
|
|
Ingress Expert |
Optional |
Optional |
Optional |
n |
n |
|
|
|
Quick Check Expert |
Optional |
Optional |
Optional |
n |
n |
|
Feature Matrix |
ONX-620 |
ONX-630 |
||||
|
n = Standard with Package. N/A = Feature not Available for this package. Optional = Feature or option can be added. (after purchase) |
TECH PACKAGE 1 |
TECH PACKAGE 2 |
TECH PACKAGE 3 |
TECH PACKAGE 4 |
TECH PACKAGE 5 |
|
|
Return signal generator |
Transmit up to 8 CW or QAM signals |
Optional |
Optional |
Optional |
n |
n |
|
Return signal generator with loopback |
Transmit and receive up to 8 CW or QAM signals with simultaneous power level measurements |
Optional |
Optional |
Optional |
n |
n |
|
Sweep testing |
Sweepless SweepTM |
N/A |
N/A |
N/A |
n |
n |
|
Forward sweep |
N/A |
N/A |
N/A |
Optional |
n |
|
|
Reverse sweep |
N/A |
N/A |
N/A |
Optional |
n |
|
|
Reverse alignment |
N/A |
N/A |
N/A |
Optional |
n |
|
|
Mobile app integration |
n |
n |
n |
n |
n |
|
|
Bluetooth |
n |
n |
n |
n |
n |
|
|
SmartID support |
SmartID and SmartID Plus (SmartID and SmartID Plus not included) |
n |
n |
n |
n |
n |
|
WiFi Advisor support |
WFED-300AC; SmartChannel Wizard (WFED-300AC not included) |
n |
n |
n |
n |
n |
|
Optical fiber scope support — P5000i (P5000i is not included) |
n |
n |
n |
n |
n |
|
|
Optical power meter support — MP-60, MP-80, FI-60 Fiber identifier (MP-60, MP-80, FI-60 Fiber identifier not included) |
n |
n |
n |
n |
n |
|
|
HomeTDR |
Optional |
Optional |
Optional |
Optional |
Optional |
|
