This sale is for a Tempo Sidekick T&N.  These are lightly used testers and may show signs of wear.  Cosmetic condition of each tester varies.

What is included:

(1) Tempo Sidekick T&N with test leads

(1) Case with strap

(1) Operational Manual

(1) Suggested Test Procedure (Reference card)







Expand                     ×

><



Previous

•



Next

<

0/1

>











TEMPO SIDEKICK® T&N

                   Cat #: 1137-5002

                UPC #: 783310605263



               Stock Photo



PRODUCT DATA

The new Sidekick T&N combines the functions of the Sidekick 7B plus the features of Transmission and Noise testing. The result is an even more versatile test set that identifies frequently missed faults as well as tests and qualifies the transmission quality of POTS lines.   Additional Features Include: - Loop Current Testing - Circuit Loss Testing - Metallic Noise Testing - Power influence testing - Load Coil Detection       The familiarity of the Sidekick's analog meter and rugged, lightweight design, combined with five new test functions, provide quality loop testing for POTS lines.       Product Features - Determines Stressed Noise Susceptibility of Dry and Working Pairs - Five Transmission and Noise Tests - Measures Resistance, AC/DC Volts, and Capacitive Kick - Minimal Drying Effect in All Ranges - Single Setup for Testing Tip-Ring, Tip-Ground, and Ring-Ground - Provides Tone for Twisted Pair or Crossed Conductor Identification - Low Battery Indicator Light - Field Replaceable Leads - Soft Case with Adjustable Strand Hook       Benefits - Works on Any Twisted Pair Application - Increases Technician Productivity - Reduces Repeat Service Calls - Increased Testing Capabilities - Reduces Training Time - Eliminates Service Interruptions - Provides Quick Return on Investment - Reduces the Number of Test Sets Required



Overview

• Quickly and accurately uncovers intermittent troubles that other test sets can’t detect
• Enables rapid and accurate testing on copper and cable pairs
• Readable in bright sunlight
• Advanced cable diagnosis and troubleshooting in a single test set
• Industry leading ease of use and operation.
• Helps technicians diagnose and troubleshoot problems with twisted pair cable
• Install, qualify, and maintain copper and CATV services
• Determines the stressed noise susceptibility of dry and working pairs
• Measures resistance, AC/DC volts, and capacitive kick
• Provides tone for twisted pair or crossed conductor identification
• Test Tip-Ring, Tip-Ground, and Ring-Ground
• Measures AC/DC Volts, Leakage, resistance, and loop current
• Performs circuit loss, circuit noise (metallic noise), and power influence test



Specifications

Attribute Name	Attribute Value
AC Voltage	0 to 200 VRMS
Circuit Loss	-15 to +1 dB
Circuit Noise	0 To 75 dBmC
DC Voltage	0 to 100 volts DC
Dimensions	10.75" x 4.25" x 2.5"
Leakage	Rx10K: Reads 0 to 20 M
Loop Current	0 to 100 mA
Power	Four AA batteries
Power Influence	50 - 100 dBmC
Resistance	Rx1: Reads 0 to 2000 | Rx1K: Reads 0 to 2 M
Stress Test	0 To 82 dBmC
Type	T And N Series
Operating Temperature	-20°C to +60°C
Voltage Measurement	DC Voltage: 0 to 100 volts DC | AC Voltage: 0 to 200 Vrms
